Silver nanoparticles may become key ingredient of emission-free power

Novel method allows for converting energy produced into emission-free power
silvercreditdkosig-istock-gettyimagesplus-gettyimages
An artist's rendering of silver particles. New research related to silver is expected to accelerate the development of advanced modules for power generation and other uses. | DKosig / iStock / Getty Images Plus / Getty Images

An international team of scientists led by a University of Houston physicist has reported a new approach to constructing thermoelectric modules. The novel method allows for converting the energy they produce into emission-free power.

Peltier modules or thermoelectric modules are thermal control devices that have both warming and cooling effects. By passing an electric current through the modules, it is possible to change the surface temperature and keep it at a target limit. These modules are common in power generation as they can be used for both heating and cooling thereby making them highly suitable for precise temperature control applications.

In a paper published in the journal Nature Energy, the University of Houston researchers said that their invention uses silver nanoparticles to connect the modules’ electrodes and metallization layers.

The work is expected to accelerate the development of advanced modules for power generation and other uses.

In the article, the group explains that the use of silver nanoparticles was tested for stability in modules built of three different state-of-the-art thermoelectric materials, designed to operate across a wide range of temperatures.

“Thermoelectric materials have drawn increasing interest because of their potential as a source of clean energy, produced when the material converts heat – such as waste heat generated by power plants or other industrial processes – into electricity by exploiting the flow of heat current from a warmer area to a cooler area,” the release notes. “But taking advantage of that ability requires finding a material that can connect the hot and cool sides of the material both electrically and thermally, without interfering with the material’s performance.”

According to the scientists, the connective material, or solder, is normally melted to create an interface between the two sides. That means the solder must have a higher melting point than the operating temperature of the device in order to remain stable while the device is working. If the thermoelectric material operates at hotter temperatures, the connective layer will re-melt.

Finding the sweet spot

Zhifeng Ren, director of the Texas Center for Superconductivity at UH and a corresponding author on the paper, also noted that if the connective material has too high a melting point it can cause problems as well because high temperatures can affect the stability and performance of the thermoelectric materials during the connection process.

“The ideal connective material, then, would both have a relatively low melting point for assembling the module, so as not to destabilize the thermoelectric materials, but then be able to withstand high operating temperatures without re-melting,” Ren said.

Silver has valuable properties for such a connective material, with high thermal conductivity and high electrical conductivity. But it also has a relatively high melting point, at 962 degrees Celsius, which can affect the stability of many thermoelectric materials.

For this work, thus, the researchers took advantage of the fact that silver nanoparticles have a much lower melting point than bulk silver. The nanoparticles returned to a bulk state after the module was assembled, regaining the higher melting point for operations.

“If you make silver into nanoparticles, the melting point could be as low as 400 degrees or 500 degrees C, depending on the particle size. That means you can use the device at 600 C or 700 C with no problem, as long as the operating temperature remains below the melting point of bulk silver, or 962 C,” Ren said.

Testing silver nanoparticles

The researchers tested the silver nanoparticles with three well-known thermoelectric materials, each of which operates at a different temperature.

A lead tellurium-based module, which works at a low temperature of about 300 C to 550 C produced a heat-to-electricity conversion efficiency of about 11% and remained stable after 50 thermal cycles.

They also used the silver nanoparticles as the connective material in modules using low-temperature bismuth telluride and a half-Heusler high-temperature material, indicating the concept would work for a variety of thermoelectric materials and purposes.

Different materials are used depending on the intended heat source, Ren said, to ensure the materials can withstand the applied heat.

“But this paper proves that whatever the material, we can use the same silver nanoparticles for the solder as long as the applied heat does not go above 960 degrees C, in order to remain below the melting point of bulk silver.”
